Description | CEMA, DIN, JIS, AS, SABS, ISO Standard Design & JUXIN ODM |
Pipe | 1) Material : Q235 carbon steel equal to DIN S235JR 2) Roller Diameter : φ63.5mm ~ φ219mm / 2 1/2 inch ~ 8 5/8 inch 3) Roller Length: 150mm ~ 3000 mm 4) Thickness : 3.0 ~6.0 mm |
Shaft | 1) Material : 45# steel equal to DIN C45 2) Cold-drawn bright round steel 3) Shaft Diameter: 20mm, 25mm, 30mm, 40mm, 45mm, 50mm |
Bearing | 1) Single Row Deep Groove Ball Bearing 2RS&ZZ with C3 clearance 2) Brand: SKF,FAG,NSK,HRB, LYC, ZWZ or according to your requirement |
Bearing Housing | 1) Material : Q235 carbon steel equal to DIN S235JR 2) Cold press working fit ISO M7 accuracy 3) Material thickness: 2.5mm ~ 5.0mm |
Seals | 1) Labyrinth seal, nylon 6 material 2) JUXIN's patented product |
Grease | 2# Lithium grease lubricant |
Painting | 1) Ordinary painting, hot galvanized painting, Powder painting 2) Color: Black, red, yellow, blue or according to your requirement |







Qustions | Answer |
Plant Size | 65,000 Square Meters |
Sample Policy | sample is available for free.But we don't bear the Express cost. |
MOQ | 10 sets for idlers;1 pcs for pulley |
Customization | Accept Customization |
Delivery Time | 15-20days after receiving the deposit |
Payment Term | 30% T/T in advance, then 70%T/T before shipment. |
