H-Lift manual hand chain hoists are commonly known as chain blocks and are designed for heavy duty lifting and materials handling operations. Chain blocks raise and lower loads by pulling on the hand chain. Chain blocks can be of single or double fall configurations depending on the capacity of the block.
Characteristics of H-Lift 30T Industry Hand Chain Hoist
1, Automatic double pawl braking system.
2, Double cover protection.
3, Light weight robust construction.
4, Low effort to lift maximum load.
5, Extra thick asbestos free friction discs.
6, Fully forged hooks are fitted with safety latches as standard.
7, High grade alloy load chain.
8, Zinc plate hnd chain as standard.
9, Sealed bearing(optional).
10, Unique hand wheel cover for guiding hand chain.
11, Complies with EC Council Directive 2006/42/EC Machinery. ASME B30.16, AS 1418.2.
12, G-80 RUD load chain from Germany or FEC load chain from Japan(optional).
13, Built in overload protection device(optional)
14, Capacity of chain hoist: 0.5t-30t
Company information:
H-Lift, an ISO 9001 certified firm by Lloyd's Register and a member of LEEA(Lifting Equipment Engineers Association), specializes in the field of lifting & hoisting equipment, webbing and round sling, Ratchet Tie Down and lashing equipment, chain & chain sling, wire rope and wire rope sling, material handling, rigging hardware & other products.
Specification of manual hand chain hoist
Other lifting equipments are also available:
Characteristics of H-Lift 30T Industry Hand Chain Hoist
1, Automatic double pawl braking system.
2, Double cover protection.
3, Light weight robust construction.
4, Low effort to lift maximum load.
5, Extra thick asbestos free friction discs.
6, Fully forged hooks are fitted with safety latches as standard.
7, High grade alloy load chain.
8, Zinc plate hnd chain as standard.
9, Sealed bearing(optional).
10, Unique hand wheel cover for guiding hand chain.
11, Complies with EC Council Directive 2006/42/EC Machinery. ASME B30.16, AS 1418.2.
12, G-80 RUD load chain from Germany or FEC load chain from Japan(optional).
13, Built in overload protection device(optional)
14, Capacity of chain hoist: 0.5t-30t
Company information:
H-Lift, an ISO 9001 certified firm by Lloyd's Register and a member of LEEA(Lifting Equipment Engineers Association), specializes in the field of lifting & hoisting equipment, webbing and round sling, Ratchet Tie Down and lashing equipment, chain & chain sling, wire rope and wire rope sling, material handling, rigging hardware & other products.
Specification of manual hand chain hoist
| CH-B TYPE CHAIN HOIST | |||||||||||
| Model | CHB005 | CHB010 | CHB015 | CHB020 | CHB030 | CHB050 | CHB100 | CHB200 | CHB300 | CHB500 | |
| Capacity | t | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 | 20 | 30 | 50 |
| Standard lift | m | 2.5 | 2.5 | 2.5 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
| Proof Load | kN | 7.5 | 15 | 22.5 | 30 | 45 | 75 | 150 | 250 | 375 | 625 |
| Effort Required to lift Rated Load | N | 200 | 320 | 360 | 365 | 385 | 435 | 435 | 435X2 | 435X2 | 435X2 |
| No. of Falls of Load Chain | 1 | 1 | 1 | 1 | 2 | 2 | 4 | 8 | 12 | 22 | |
| Load Chain | mm | 6 | 6 | 8 | 8 | 8 | 10 | 10 | 10 | 10 | 10 |
| Dimensions(mm) | A | 137.5 | 146.5 | 170 | 170 | 170 | 190 | 190 | 209 | 312 | 496 |
| B | 137 | 162 | 183 | 194 | 220 | 288 | 384 | 625 | 691 | 958 | |
| C | 270 | 317 | 399 | 414 | 465 | 618 | 798 | 890 | 1380 | 2578 | |
| D | 35 | 35.5 | 45 | 42.5 | 50 | 64 | 85 | 110 | 110 | 170 | |
| K | 28 | 26 | 32.5 | 32 | 37 | 46 | 50 | 81 | 81 | 125 | |
| Net Weight | kg | 8.4 | 10.5 | 15.5 | 18.5 | 21.2 | 41.8 | 81.7 | 173 | 238.5 | 1092 |
| Extra Weight per Metre of Extra Lift | kg | 1.7 | 1.7 | 2.3 | 2.3 | 3.7 | 5.6 | 9.7 | 19.4 | 29.1 | 53.4 |
